Add an output device to your BRNKL Black.
The BRNKL Black includes two built-in outputs that can be used to control external devices.
-
Type: Relay outputs (switch to ground).
-
Capacity: Up to 2 A maximum load each.
-
Use Cases: Can be wired to control small loads directly (e.g., a light, buzzer, or siren) or to trigger a higher-capacity relay for larger devices.
-
Polarity: Since the outputs switch to ground, ensure the device being controlled is wired with the positive side supplied separately.
Important: Do not exceed the 2 A limit. For higher-draw devices, use these outputs to drive an external relay instead.
The outputs are connected using the supplied connector cable:
See the connection guide here.
