Add bilge pump

Check, review, and find out about bilge pump activity by adding a bilge pump to your BRNKL using the supplied connector cable:

img plug connector cable brnkl blue.png

Connect bilge pump

  • On the bilge pump, find the MANUAL lead .

    • Typically a brown and white wire.


  • Connect the MANUAL lead to any available input channel on the BRNKL connector cable.



Bilge pump connection settings

Set a wired channel on your BRNKL to act as a bilge pump connection.

To set bilge pump connection, follow these steps:

A | Open channel settings

Using your browser device, on the BRNKL-connected local network:

  1. Go to the BRNKL Device Manager, select Settings img settings icon.svg

    img brnkl device settings(1).png

  2. From the Devices menu select Inputs.

img settings devices nmea 2001.png

  1. In INPUTS, find the channel (1-7) used to connect the device to the BRNKL.

img select wired input channel.png

  1. Select the channel to open its settings.

img wired input channel settings.png

B | Name channel

In the selected channel settings:

  1. Replace the default Name with a descriptive name.

    • Use 12 or fewer characters.

      img enter new name.png

  2. Save.

    img settings nmea 2000 save.png

C | Set connection to bilge

In the selected channel settings:

  1. In Input type, select Bilge.


D | Set up bilge pump monitoring

In the selected Bilge activity settings:

  • To check bilge pump status, turn on Monitor.

    • BRNKL will monitor and display bilge pump status:

      • On the BRNKL Device Manager Dashboard, in real time.

      • In the BRNKL app (if connected), updated every 15 minutes.


  • To display the number of recent bilge pump events, turn on 24 hour count.

  • BRNKL will display the number of bilge pump events in the past 24 hours:

    • On the BRNKL webpage Dashboard.

    • In the BRNKL mobile app, updated every 15 minutes.


  • Save when complete.

E | Set up bilge pump activity alerts

  • To find out when a bilge pumps for too often or too long, turn on Alert.

    • BRNKL will send alerts when the bilge pump is active for a specified duration and frequency.


    • To find out about events while BRNKL is Disarmed, turn on Critical Alert.

      • BRNKL will send alerts while Armed or Disarmed.


  • To change the duration of a pumping event, enter a new Bilge on time value.


  • To change the frequency of pumping events for Long period alert or Short period alert:

    • Enter a new time period.

    • Enter a new limit for the frequency of pumping events.


  • Save when complete.

F | Set up bilge pump activity recording

  • To review bilge pump activity history, turn on Record.

    • BRNKL will record and store bilge pump activity data.


  • Save when complete.
